The EMV tents from Telemeter Electronic provide a multitude of advantages for radio emitter enthusiasts. These tents are ideal for laboratory tests and measurements in the frequency range of 30 MHz to 16 GHz. With a shielding capability of up to 95 dB and their flexibility and lightweight design, they are portable and can be set up and taken down quickly.
Table of Contents: What awaits you in this article
Cost-effective testing of large objects with flexible EMV tents
The flexible concept of EMV tents allows for testing large test objects without the expensive and complicated transportation to external testing laboratories. Even large objects such as trucks and satellites can be tested in these tents. This saves time and costs for transportation and allows tests to be conducted directly on site.
Telemeter Electronic offers customizable and standard EMV tents
Telemeter Electronic provides a range of EMV tents, including both customized options and two standard models. The T-Series measures 610 x 1220 x 610 mm (L x W x H) internally, while the P-Series measures 2150 x 2150 x 2180 mm (L x W x H). This variety allows customers to select the EMV tent that best suits their specific requirements.
High-Shielding EMV Tents for Lab Tests and Measurements
The EMV tents from Telemeter Electronic are made of nylon fabric coated with silver, copper, nickel, and tin (Ag/Cu/Ni/Sn), known as RS coating. This coating provides an average shielding effectiveness of 95 dB in the frequency range of 30 MHz to 16 GHz. These tents comply with the IEEE 299/2006 standard and can be used in Class A300 (Class 1000) cleanrooms. They are also suitable for temperatures ranging from -30 °C to +90 °C.
Telemeter Electronic offers advanced measurement chambers for precise testing
Telemeter Electronic offers advanced measurement chambers in addition to EMV tents. These chambers include individual control, measurement, and operating concepts, up to fully automatic control. This allows for even more precise and comprehensive measurements to be carried out.
Flexible and Portable EMV Tents for Efficient On-Site Testing
The EMV tents from Telemeter Electronic provide a flexible and practical solution for laboratory tests and measurements in the frequency range of 30 MHz to 16 GHz. With their high shielding, easy portability, and quick set-up and dismantling, they enable efficient on-site testing. Additionally, Telemeter Electronic offers customized solutions and advanced measurement capabilities to meet individual requirements.
