Infineon Technologies introduces the EZ-USB FX10, a powerful USB controller


Infineon Technologies AG proudly introduces the latest addition to the EZ-USB(TM) family of programmable USB peripheral controllers: the EZ-USB FX10. This controller, with its continuously evolving features and impressive performance, enables the development of USB devices that meet the highest demands of AI, image processing, and emerging applications. With its fast connectivity at USB 10 Gbps and LVDS interfaces, the EZ-USB FX10 increases the overall bandwidth by three times compared to its predecessor.

EZ-USB FX10: Powerful USB Controller with High-Speed Data Transfer

The EZ-USB FX10 is a powerful USB peripheral controller equipped with two ARM Cortex-M4 and M0+ core CPUs, 512 KB Flash, 128 KB SRAM, 128 KB ROM, and seven serial communication blocks (SCBs). It also features a cryptography accelerator and a high-bandwidth data subsystem. The data subsystem allows for DMA data transfers between LVDS/LVCMOS and USB ports at impressive speeds of up to 10 Gbit/s.

The EZ-USB FX10 features an additional 1 MB SRAM for USB data buffering, enhancing data transmission capabilities. With USB-C connector orientation detection and flip-mux functionality, this peripheral controller provides an integrated solution without the need for external logic. This makes the EZ-USB FX10 an ideal choice for developers seeking a powerful and flexible USB controller.

Compact design of EZ-USB FX10 saves PCB space

The EZ-USB FX10 features a compact 10 x 10 mm² BGA package, making it an ideal choice for space-constrained PCB designs. By reducing the footprint, it optimizes the bill of materials (BOM) and allows for the inclusion of additional components. Furthermore, its direct USB-C connection capability eliminates the need for high-speed signal multiplexers, streamlining the design process.

The Quick Start Development Kit for the EZ-USB FX10 includes firmware and a configuration tool, ensuring a straightforward integration process. Additionally, the EZ-USB FX10 DVK comes with a standard FPGA Mezzanine Card (FMC) connector, enabling easy connection to FPGA boards. This feature allows developers to seamlessly incorporate the EZ-USB FX10 into their existing FPGA-based systems, expanding its functionality and versatility.

The EZ-USB FX10 development kit is complemented by an all-in-one programming and debugging accessory card. This card provides developers with a comprehensive set of application guidelines for hardware and software design, enabling the development of high-performance devices for various applications.

Infineon Technologies AG Introduces EZ-USB FX10: A High-Performance USB Peripherals Controller

The EZ-USB FX10 from Infineon Technologies AG is an exceptional USB peripheral controller that meets the requirements of demanding applications. With its fast connectivity, powerful CPUs, and extensive features, it offers developers the ability to create high-performance USB devices. Its compact design and easy integration make it ideal for space-constrained applications. With the EZ-USB FX10, developers are well-equipped to successfully implement their ambitious projects.

Infineon Technologies AG Announces Availability of EZ-USB FX10 Peripheriecontroller

The EZ-USB FX10 peripheral controller, housed in a compact 10 x 10 mm² BGA package, is scheduled to be released in the fourth quarter of 2024. It offers developers a powerful and flexible solution for high-performance USB devices. The availability of development samples allows for early testing and integration into product designs.
